Rodeo Tripod MINI Special for VIDEOMIC

Be the first to make an inquiry about this product!
System
The channels 3 channels in total
RF frequency range 5.725 GHz to 5.875 GHz
Operating range 98.4 '/ 30 m, line of sight
Frequent response 40 Hz to 18 kHz, ± 1 dB
THD + N 92 dB
Sampling frequency 48 kHz
Bit depth 16 bits
Latency 18 ms
Antenna gain 3 dBi
Operating temperature 32 to 122 ° F / 0 to 50 ° C
Storage temperature -4 to 131 ° F / -20 to 55 ° C
Transmitter
RF power output 30 mW (15 dBm)
1/8 "/ 3.5 mm TRS microphone input,
Maximum blocking of 160 mV / -13 dBu
1.8 V power plug
Line input 1/8 "/ 3.5 mm TRS, lock
maximum 2 V / 8 dBu, 50 VDC insulation
Battery Type: Rechargeable Li-ion battery LP-E17, Removable capacity: 7.2 V / 1000 mAh
Battery life: 6.5 hours (average)
Power consumption: 180 mA, 6 V
Charge with battery charger included
Dimensions 4.45 x 2.52 x 1.10 "/ 113 x 64 x 28 mm
Weight 5.96 oz / 169 g, with battery
Receiver
98 dB sensitivity
Line output 1/8 "/ 3.5 mm TRS, lock
4 x microphone input gain, 50 VDC isolation
Headphone output 1/8 "/ 3.5 mm TRS, lock
max. 70 mW to 32 ohms, 10 VDC insulation
Battery Type: Rechargeable Li-ion battery LP-E17, Removable capacity: 7.2 V / 1000 mAh
Battery life: 6.5 hours (average)
Power consumption: 180 mA, 6 V
Charge with battery charger included
Dimensions 4.45 x 2.52 x 1.10 "/ 113 x 64 x 28 mm
Weight 5.96 oz / 169 g, with battery
